Deploying SGLang with PD disaggregation via Shepherd Model Gateway¶

dstack is an open-source control plane that simplifies GPU orchestration for both training and inference — across cloud providers, hardware vendors, and frameworks. Over the past year, we've been steadily making inference a first-class citizen in dstack.

About SMG¶

Today, we're taking the next step: native support for Shepherd Model Gateway (SMG) — a high-performance inference gateway that has evolved from the SGLang Router into a standalone project under the LightSeek Foundation. With the latest update, deploying SGLang with Prefill-Decode disaggregation on dstack becomes simpler and more flexible.

Now a standalone project, SMG aims to support various serving backends — including SGLang, vLLM, and TensorRT-LLM. Written in Rust, it provides cache-aware routing, PD disaggregation, circuit breakers, rate limiting, and 40+ Prometheus metrics out of the box.

PD disaggregation

Prefill-Decode disaggregation separates the two phases of LLM inference — prompt processing (prefill) and token generation (decode). Prefill is compute-bound and parallel; decode is memory-bound and sequential. Running them separately improves both Time to First Token (TTFT) and end-to-end latency.

Since 0.20.17, dstack supports deploying SGLang with PD disaggregation using Shepherd Model Gateway. To do it, define three replica groups: one for SMG, one for prefill workers, and one for decode workers.

How to use SMG with dstack¶

Here's a complete service configuration that deploys zai-org/GLM-4.5-Air-FP8 with PD disaggregation using SMG and SGLang on dstack:

type: service
name: prefill-decode
image: lmsysorg/sglang:v0.5.10.post1
env:
  - HF_TOKEN
  - MODEL_ID=zai-org/GLM-4.5-Air-FP8
replicas:
  - count: 1
    # For now replica group with router must have count: 1
    commands:
      - pip install smg
      - |
        smg launch \
          --host 0.0.0.0 \
          --port 8000 \
          --pd-disaggregation \
          --prefill-policy cache_aware
    router:
      type: sglang
    resources:
      cpu: 4
  - count: 1..4
    scaling:
      metric: rps
      target: 3
    commands:
      - |
        python -m sglang.launch_server \
          --model-path $MODEL_ID \
          --disaggregation-mode prefill \
          --disaggregation-transfer-backend nixl \
          --host 0.0.0.0 \
          --port 8000 \
          --disaggregation-bootstrap-port 8998
    resources:
      gpu: H200
  - count: 1..8
    scaling:
      metric: rps
      target: 2
    commands:
      - |
        python -m sglang.launch_server \
          --model-path $MODEL_ID \
          --disaggregation-mode decode \
          --disaggregation-transfer-backend nixl \
          --host 0.0.0.0 \
          --port 8000
    resources:
      gpu: H200
port: 8000
model: zai-org/GLM-4.5-Air-FP8
# Custom probe is required for PD disaggregation.
probes:
  - type: http
    url: /health
    interval: 15s

The SMG replica group must define router: sglang.

The configuration defines three replica groups. The first runs SMG as the router on a CPU node. The second and third run prefill and decode workers respectively, using NIXL for KV cache transfer between them. Prefill scales from 1 to 4 replicas and decode from 1 to 8, both based on requests per second.

$ HF_TOKEN=...
$ dstack apply -f prefill-decode.dstack.yml

Because dstack is not tied to any specific cloud or cluster manager, this same configuration works across any GPU cloud, any Kubernetes cluster, or any non-Kubernetes on-prem environment managed through dstack fleets.

What's coming next¶

We're actively working on expanding the inference stack in dstack. Here's what's coming:

gRPC — enabling SMG's gRPC mode, which will also allow using vLLM with Shepherd Model Gateway for PD disaggregation.
NVIDIA Dynamo — native support for NVIDIA's inference framework.
TTFT and ITL — autoscaling based on Time to First Token and Inter-Token Latency, complementing the current RPS metric.
AMD — validated configurations for running PD disaggregation on AMD Instinct GPUs.

Why vendor-agnostic?¶

The inference stack is evolving fast — new serving engines, new routing strategies, new hardware. Teams shouldn't have to rebuild their orchestration every time a piece of the stack changes. dstack provides a stable, vendor-agnostic layer that lets you adopt the best tools for each job — whether that's SGLang or vLLM, NVIDIA or AMD, cloud or on-prem — without locking into any single vendor's platform.

Our commitment remains the same: simplify both training and inference across vendors through open-source.

Huge thanks to the SGLang community for collaboration and support. The gateway's evolution into a standalone project have been instrumental in making this integration possible.
